rare earth N35 disc ndfeb magnet with strict tolerance Admin Edit

Competitive price with High quality! Strict tolerance control:+/-0.02mm. Quality Certificate: SO9001 ,ISO/TS16949,ISO14001,GS/T28001

  • Min. Order: 1000 Piece/Pieces
  • Trade Term: FOB,CFR,CIF
  • Payment Terms: L/C, T/T, WU
  • Place of Origin: Zhejiang, China (Mainland)
  • Means of Transport: Ocean, Air
  • Production Capacity: 10000000 PCS/M
  • Packing: Standard export carton

  • Product Description

    Product Attribute

    Spec. D2.5X3

    Tolerance: +/-0.02MM

    Coating : NI PLATED

    GAUSS: 2900GS



    1,Why Choose US:

    Quality Assurance :

    -The Company achieved certificate of ISO9001 in 2005 and certificate of ISO/TS16949,ISO14001,GS/T28001 in 2014.

    Patent & Licence

    -We Could supply Magnet Patent & Licence to the end users.

    Soon Feedback

    -We will reply you all the questions within 24 hours.

    Payment terms:

    We Could Accept monthly payment.

    Soonest delivery

    Lead time: ABout 7-20 days

    Favourable  price

    Try our best to save your Money.



    2.Our Similar demension magnet with  thcikness in stock:

    a, N35sh -D2*1.5-NICUNI

    b,N35 -D2*2-NICUNI coating

    c,N35 -D2X1-Zinc coating

    d,N35 -D2X1.6-NiCUNI coating

    e,N35SH -D2X11-Ni coating



    3.Below is the different Magnetizing conditions of Ring Magnet



    Coating: Ni ,Zn ,Ag,plastic,phosphor







    4.Sintered NdFeB Magnet Performance:

     N30-N52, 33M-50M, 30H-50H, 30SH(T)-45SH(T), 30UH-44UH and 30EH-40EH;



    Item

    Grade

    Residual Induction

    Coercive Force

    Intrinsic Coercive Force

    Max. Energy Product

    Tw

    Br

    Hcb

    Hcj

    (BH)Max

    L/D=0.7

    T

    kGS

    kA/m

    kOe

    kA/m

    kOe

    kJ/m³

    MGOe

    °C

    N

    N35

    1.17-1.24

    11.7-12.4

    ≥860

    ≥10.8

    ≥955

    ≥12

    263-295

    33-37

    ≤80

    N38

    1.22-1.30

    12.2-13.0

    ≥860

    ≥10.8

    ≥955

    ≥12

    287-318

    36-40

    ≤80

    N40

    1.26-1.32

    12.6-13.5

    ≥860

    ≥10.8

    ≥955

    ≥12

    302-334

    38-42

    ≤80

    N42

    1.29-1.35

    12.9-13.5

    ≥860

    ≥10.8

    ≥955

    ≥12

    318-350

    40-44

    ≤80

    N45

    1.32-1.38

    13.2-13.8

    ≥860

    ≥10.5

    ≥955

    ≥12

    334-366

    42-46

    ≤80

    N48

    1.37-1.43

    13.7-14.3

    ≥836

    ≥10.8

    ≥876

    ≥11

    358-390

    45-49

    ≤80

    N50

    1.40-1.45

    14.0-14.5

    ≥836

    ≥10.5

    ≥876

    ≥11

    374-406

    47-51

    ≤80

    N52

    1.42-1.48

    14.2-14.8

    ≥836

    ≥10.5

    ≥876

    ≥11

    390-422

    49-53

    ≤80

    N54

    1.45-1.51

    14.5-15.1

    ≥836

    ≥10.5

    ≥876

    ≥11

    398-438

    50-55

    ≤80

    M

    N35M

    1.17-1.25

    11.7-12.4

    ≥860

    ≥10.8

    ≥1114

    ≥14

    263-295

    33-37

    ≤100

    N38M

    1.22-1.30

    12.2-13.0

    ≥915

    ≥11.5

    ≥1114

    ≥14

    287-318

    36-40

    ≤100

    N40M

    1.26-1.32

    12.6-13.5

    ≥939

    ≥11.8

    ≥1114

    ≥14

    302-334

    38-42

    ≤100

    N42M

    1.29-1.35

    12.9-13.5

    ≥955

    ≥12.0

    ≥1114

    ≥14

    318-350

    40-44

    ≤100

    N45M

    1.32-1.38

    13.2-13.8

    ≥987

    ≥12.4

    ≥1114

    ≥14

    334-366

    42-46

    ≤100

    N48M

    1.37-1.43

    13.7-14.3

    ≥1019

    ≥12.8

    ≥1114

    ≥14

    358-390

    45-49

    ≤100

    Item

    Grade

    Residual Induction

    Coercive Force

    Intrinsic Coercive Force

    Max.Energy Product

    Tw

    Br

    Hcb

    Hcj

    (BH)Max

    L/D=0.7

    T

    kGS

    kA/m

    kOe

    kA/m

    kOe

    kJ/m³

    MGOe

    °C

    SH

    N33SH

    1.14-1.21

    11.4-12.1

    ≥852

    ≥10.7

    ≥1592

    ≥20

    247-279

    31-35

    ≤150

    N35SH

    1.17-1.24

    11.7-12.4

    ≥876

    ≥11

    ≥1592

    ≥20

    263-295

    33-37

    ≤150

    N38SH

    1.22-1.30

    12.2-13.0

    ≥915

    ≥11.5

    ≥1592

    ≥20

    287-318

    36-40

    ≤150

    N40SH

    1.26-1.32

    12.6-13.5

    ≥939

    ≥11.8

    ≥1592

    ≥20

    302-334

    38-42

    ≤150

    N42SH

    1.29-1.35

    12.9-13.5

    ≥963

    ≥12.1

    ≥1592

    ≥20

    318-350

    40-44

    ≤150

    N45SH

    1.32-1.38

    13.2-13.8

    ≥994

    ≥12.5

    ≥1592

    ≥20

    335-366

    42-46

    ≤150

    UH

    N30UH

    1.08-1.16

    10.8-11.6

    ≥812

    ≥10.2

    ≥1990

    ≥25

    223-255

    28-32

    ≤180

    N33UH

    1.14-1.21

    11.4-12.1

    ≥852

    ≥10.7

    ≥1990

    ≥25

    247-279

    31-35

    ≤180

    N35UH

    1.17-1.24

    11.7-12.4

    ≥876

    ≥11

    ≥1990

    ≥25

    263-295

    33-37

    ≤180

    N38UH

    1.22-1.30

    12.2-13.0

    ≥915

    ≥11.5

    ≥1990

    ≥25

    287-318

    36-40

    ≤180

    N40UH

    1.26-1.32

    12.6-13.5

    ≥939

    ≥11.8

    ≥1990

    ≥25

    321-334

    38-42

    ≤180

    N42UH

    1.29-1.35

    12.9-13.5

    ≥963

    ≥12.1

    ≥1990

    ≥25

    318-350

    40-44

    ≤180

    EH

    N30EH

    1.08-1.15

    10.8-11.5

    ≥812

    ≥10.2

    ≥2388

    ≥30

    223-255

    28-32

    ≤180

    N33EH

    1.14-1.21

    11.4-12.1

    ≥851

    ≥10.7

    ≥2388

    ≥30

    247-279

    31-35

    ≤180





    5.Ndfeb Magnet Application:

     Gradually from the traditional communication, computer,  nuclear magnetic resonance (NMR), wind turbine, electric vehicles, etc.



    6.Various shapes and sizes :

    Block Ring,Arc,Countersunk,Round,Segment,Complex,Horseshoe,Trapezoid Or produce by customers' request,




    7.FAQ

    1)Q: Do not know which kind magnet use?

    A: We have professional engineers in the magnetic industry for more than 10 years, To give you our best advice.

    2)Q:  How to meet customers 's short leadtime?

    A: We have own factory to support your urgent orders.

    3)Q:How to pay us?

     A: Could accept T/T ,L/C,West Union,O/A  as our agreement.

    4) Q:For the after-sales service

     A: If have something not satisfied ,we could solve it well and sonn to keep our business longer.

    5) How to visit us?

    A: If you interest in visit us ,Let us know ASAP .We will arrange our schedule for you.

    6) How to get samples?

    For the samll samples ,we could supply free of charge.



    8. Our factory EQUIPMENT:

    small disc permanent neodymium magnet with Ni plated









    Delivery Date: 7-15 days Application: Industrial Magnet
    Shape: Others Type: Permanent
    Composite: Neodymium Magnet Brand Name: HS
    Spec.: D2.5x3 Coating: No
    Grade: N35 Tolerance: +/- 0.02
    Magnetizing direction: through thickness ROHS: Yes
    Magnetization: Yes Avalable: Stock
    Certificate: ISO9001 ,ISO/TS16949,ISO14001,GS/T28001 Material: Neodymium Magnet
  • Min. Order: 1000 Piece/Pieces
  • Trade Term: FOB,CFR,CIF
  • Payment Terms: L/C, T/T, WU
  • Place of Origin: Zhejiang, China (Mainland)
  • Means of Transport: Ocean, Air
  • Production Capacity: 10000000 PCS/M
  • Packing: Standard export carton
  • Delivery Date: 7-15 days
  • Application: Industrial Magnet
  • Shape: Others
  • Type: Permanent
  • Composite: Neodymium Magnet
  • Brand Name: HS
  • Spec.: D2.5x3
  • Coating: No
  • Grade: N35
  • Tolerance: +/- 0.02
  • Magnetizing direction: through thickness
  • ROHS: Yes
  • Magnetization: Yes
  • Avalable: Stock
  • Certificate: ISO9001 ,ISO/TS16949,ISO14001,GS/T28001
  • Material: Neodymium Magnet
